Specifications
Supported frequency range
- US and Canada models: 470 MHz to 616 MHz
- European model: 470 MHz to 714 MHz
Input/output impedance
- 50 Ω
Input/output connectors
- BNC-R type
Antenna input connectors
- 2-channel (a, b) × 2-input
Divider output connectors
- 2-channel (a, b) × 6-output
Transmission loss
- Within +3 dB/−6 dB (between antenna input and divider output)
Coupling loss between connectors
- 15 dB or higher
Rated voltage
- US and Canada models: AC 120 V
- European model: AC 220 V to 240 V
Rated power consumption
- 18 W (when supplying 160 mA to antenna booster)
Booster power supply
- DC 9 V/THRU/12 V switchable (output from antenna input connector)
Operating temperature
- 0 °C to 50 °C (32 °F to 122 °F)
Storage temperature
- −20 °C to +60 °C (−4 °F to +140 °F)
Dimensions
Front view
Rear view
Mass
- Approx. 3.3 kg (7 lb 4.4 oz)
Supplied accessories
- Power cord (1)
- Before Using This Unit (1)
- Warranty booklet (1)
Design and specifications are subject to change without notice.
