About the indicator
You can check various statuses of the keyboard with the lighting status of the keys.
Hint
- You can set the lighting color that lights up or flashes with “INZONE Hub”.
Power status
Illumination is displayed on the entire key.
- When the keyboard is turned on by connecting to a computer that is turned on
Key operation setting status
The Caps key (A) lights up. (1)
- When caps lock is enabled(2)
The Fn key (D) lights up. (1)
- When function lock is enabled(3)
Others
The Win key (B), Fn key (D), and B key (C) repeatedly flash slowly.
- When BIOS mode is on(4)
The entire key repeatedly flashes slowly.
- Updating software
The entire key flashes 4 times.
- When the initialization process is completed
For details, see “Initializing the keyboard to restore factory settings”.
(1) You can use “INZONE Hub” to turn off the lights. In this case, turn off the illumination setting.
(2) The state in which the Caps key is pressed and alphabetical input is always fixed to uppercase.
(3) The state in which the Fn key is locked by pressing the ← key while holding down the Fn key.
(4) The mode that allows the keyboard to be properly recognized by the BIOS on the legacy motherboard.
To adjust the brightness of the key lighting
- Press the upward key (E) while holding down the Fn key (D)
The light on the key becomes brighter with each press. - Press the downward key (F) while holding down the Fn key (D)
The light on the key becomes darker with each press.
