List of icons on the screen for shooting movies

The displayed contents and their positions in the illustrations are just guidelines, and may differ from the actual displays.

Descriptions are given below the indications of the icons.

Illustration of the screen when shooting movies

In addition to the icons described on this page, there are more icons for touch operations (touch function icons) that are displayed on the left or right side of the screen when you swipe the monitor. For details, refer to “Touch function icons.”

  1. Basic camera settings
    Audio level
    Audio recording off
    Focus Mode
    Clear Image Zoom/Digital Zoom
    Gamma Disp. Assist Typ.
    STBY REC
    Movie recording standby/Movie recording in progress
    1:00:12
    Actual movie recording time (hours: minutes: seconds)
    8K 4K HD
    File format of movies
    120p 100p 60p 50p 30p 25p 24p
    Frame rate of movies
    Memory card for recording / Not memory card for recording
    NO CARD
    No memory card inserted
    Nearing the rewriting upper limit of the memory card / Rewriting upper limit of the memory card reached
    Recording to both memory cards simultaneously
    1h 30m
    Recordable time of movies
    Writing data / Number of images left to write
    Remaining battery
    Remaining battery warning
    USB power supply
  2. Exposure and other settings
    1/250 1/250
    Shutter speed
    F3.5 F3.5
    Aperture value
    Exposure compensation/Metered Manual
    ISO400 ISO 400
    ISO sensitivity
    7500K A5 G5
    White Balance (Auto, Preset, Underwater Auto, Custom, Color temperature, Color filter)
    AE lock/AWB lock
    Shooting
  3. Other settings (displayed during recording standby)
    Shooting mode
    Shooting mode ( Recall Camera Setting)
    Tripod recognition
    REC Control
    4K/RAW external output
    EXT-LK
    External lock state of the time code
    00:00:00.00
    Time code (hours: minutes: seconds. frames)
    00 00 00 00
    User Bit
    Spot Focus
    Performing [Spot Focus]
    x4 Slow x4 Quick
    Slowness/quickness scale during slow-motion/quick-motion shooting
    4K(2160p) 30p / 4K(2160p) 25p /4K(2160p) 15p / 4K(2160p) 12.5p / HD(1080p) 60p / HD(1080p) 50p / HD(1080p) 30p / HD(1080p) 25p / HD(720p) 30p / HD(720p) 25p
    USB streaming output format
    Streaming : Standby / Streaming : Output
    USB streaming status
    Tracking Cancel
    Guide display for tracking
    Focus Cancel
    Guide display for canceling focusing
    Audio format
    Guide display for dials
    Touch function in shooting mode (Touch Focus/Touch Tracking/Off)
    Focus Cancel
    Tracking Cancel
    Remote Shooting (connected) / Remote Shooting (connection error)
    Connected to the cloud/Communicating with the cloud/Cloud connection error
    FTP function / FTP transfer status
    Airplane Mode
    Connected to Wi-Fi (via a Wi-Fi access point)
    Disconnected from Wi-Fi (via a Wi-Fi access point)
    Connected to Wi-Fi/Disconnected from Wi-Fi (Wi-Fi Direct)
    Connected to LAN/Disconnected from LAN
    NFC active
    Bluetooth connection available / Bluetooth connection unavailable
    Remote control
    Obtaining location information / Location information cannot be obtained
    Metering Mode
    D-Range Optimizer
    Histogram
    Digital level gauge
    Overheating warning
    Database file full / Database file error

Hint

  • Area 3 icons may not be displayed while the touch function icons are displayed. To see hidden icons, swipe the touch function icons left or right to hide the touch function icons.
