List of icons on the screen for shooting movies

The displayed contents and their positions in the illustrations are just guidelines, and may differ from the actual displays. Also, the displayed contents may vary depending on your camera’s system software (firmware) version.

Descriptions are given below the indications of the icons.

In addition to the icons described on this page, there are more icons for touch operations (touch function icons) that are displayed on the left or right side of the screen when you swipe the monitor. For details, refer to “Touch function icons.”

  1. Basic camera settings
    Audio level
    Audio recording off
    Focus Mode
    Clear Image Zoom/Digital Zoom
    Gamma Disp. Assist Typ.
    S-log3 s709 709(800%) User1 LUT OFF
    LUT
    STBY REC
    Movie recording standby/Movie recording in progress
    1:00:12
    Actual movie recording time (hours: minutes: seconds)
    4K HD
    File format of movies
    Fixed-59.94 fps / 15 fps (59.94p)
    Frame rate of movies (when [Fixed/Variable Select] is set to [Fixed]/[Variable])
    Memory card for recording / Not memory card for recording
    NO CARD
    No memory card inserted
    Nearing the rewriting upper limit of the memory card / Rewriting upper limit of the memory card reached
    Recording to both memory cards simultaneously
    1h 30m
    Recordable time of movies
    Writing data / Number of images left to write
    Remaining battery
    Remaining battery warning
    USB power supply
  2. Exposure and other settings
    1/250 1/250 180.0
    Shutter speed/Shutter angle
    F3.5 F3.5
    Aperture value
    Exposure compensation/Metered Manual
    ISO400 ISO 400
    ISO sensitivity
    800EI / 6.0E / L
    Exposure Index/Base ISO
    7500K A5 G5
    White Balance (Auto, Preset, Underwater Auto, Custom, Color temperature, Color filter)
    AE lock/AWB lock
    Shooting
  3. Other settings (displayed during recording standby)
    Shooting mode
    Shooting mode (Memory recall)
    Tripod recognition
    REC Control
    4K/RAW/DCI 4K external output
    EXT-LK
    External lock state of the time code
    00:00:00.00
    Time code (hours: minutes: seconds. frames)
    00 00 00 00
    User Bit
    Spot Focus
    Performing [Spot Focus]
    Movie self-timer
    Starting/stopping network streaming output
    High / Standard / Low / HD (1080p) 59.94p 9.0M
    Image quality setting for network streaming output
    Streaming : Standby / Output / Connecting / Connect. Err. / Not Connect
    Network streaming status
    USB connection mode (USB streaming)
    4K(2160p) 29.97p / 4K(2160p) 25p /4K(2160p) 14.99p / 4K(2160p) 12.5p / HD(1080p) 59.94p / HD(1080p) 50p / HD(1080p) 29.97p / HD(1080p) 25p / HD(720p) 29.97p / HD(720p) 25p
    USB streaming output format
    Streaming : Standby / Streaming : Output
    USB streaming status
    Tracking Cancel
    Guide display for tracking
    Focus Cancel
    Guide display for canceling focusing
    Tracking+AE Cancel
    Guide display for tracking+AE
    Focus+AE Cancel
    Guide display for focus+AE
    Touch AE Cancel
    Guide display for touch AE
    Lock Composition/ Cancel Lock Composition
    Guide display for locking the composition with [Framing Stabilizer]
    Audio format
    Guide display for dials
    Anti-flicker Tv Scan
    Focus Cancel
    Touch Focus+AE cancel/TouchTracking+AE cancel/Touch AE cancel
    Tracking Cancel
    Lock composition/Cancel lock composition
    Remote Shooting (connected) / Remote Shooting (connection error)
    Connected to the cloud/Communicating with the cloud/Cloud connection error
    Connected with FTP / FTP communication in progress / FTP connection error
    Transferring to smartphone / Transfer error
    Airplane Mode
    Connected to Wi-Fi (via a Wi-Fi access point)
    Disconnected from Wi-Fi (via a Wi-Fi access point)
    Connected to Wi-Fi/Disconnected from Wi-Fi (Wi-Fi Direct)
    Connected to LAN/Disconnected from LAN (When using a USB-LAN conversion adaptor)
    Bluetooth connection available / Bluetooth connection unavailable
    Remote control
    Obtaining location information / Location information cannot be obtained
    Metering Mode
    D-Range Optimizer
    Histogram
    Digital level gauge
    Overheating warning
    Database file full / Database file error
    Cooling fan malfunction warning

Hint

  • Area 3 icons may not be displayed while the touch function icons are displayed. To see hidden icons, swipe the touch function icons left or right to hide the touch function icons.
