HOME (Home) button

When you press the HOME button in the movie recording mode, the home screen appears on the monitor, allowing you to check recording and device settings all at once. You can also change recording settings by touching the screen.

Illustration indicating the position of the home button

Home screen

Press the HOME button in the movie recording mode to display the home screen. Press the HOME button again to return to the recording screen.

Hint

  • When [Swipe Down] under [Shooting Screen] is set to [Open Home Screen], the home screen can be displayed using touch operations by swiping downward quickly on the shooting screen.

Illustration of the home screen

Setting values for movie recording are displayed in areas 1 to 6. Touching each item will take you to the setting screen for that item.

  1. FPS (Frame rate)
    • You can switch between [Fixed] and [Variable] from this screen. When set to [Variable], you can also set the frame rate.
  2. ISO/Base ISO
    • When [Log Shooting] is set to [Off] or [Flexible ISO], the ISO value is displayed. When [Log Shooting] is set to [Cine EI Quick] or [Cine EI], the EI value of the Base ISO is displayed.
  3. Shutter angle/Shutter speed
    • When [Shutter Mode] is set to [Speed], the shutter speed is displayed.
  4. Aperture
    • By changing the settings in [Home (Lower Left)], you can change the item displayed from [Aperture] to [ND Filter].
  5. Picture Profile/Select LUT
    • When [Log Shooting] is set to [Off], [Gamma] and [Color Mode] for [Picture Profile] are displayed. When [Log Shooting] is set to an item other than [Off], the setting value of [Select LUT] is displayed.
  6. White Balance
  7. Other camera settings
    • Displays the camera status and setting values. Settings cannot be changed even if touched.

Hint

  • To select a setting item from 1 to 6, you can use the control wheel in addition to touch controls. Press the center of the control wheel to highlight an item, and then use the top/bottom/left/right side of the control wheel to move the highlighted position. Press the center button again to confirm your selection.


Switching to the menu screen or Fn menu screen

Just as when switching from the shooting screen to the menu screen or Fn menu screen, to switch from the home screen to the menu screen or Fn menu screen, press the MENU button or Fn button. Pressing either button again will return to the home screen. Also, you can switch to the home screen by pressing the HOME button on the menu screen or Fn menu screen.

Illustration of the home screen, menu screen, and function menu screen transition

(A): Menu screen

(B): Home screen

(C): Fn menu screen

(D): Recording screen

Note

  • The home screen is not displayed in the still image shooting mode.
  • You cannot change any settings other than those in the lower left of the home screen.
TP1002005041
