Front side

Illustration of the front side of the camera

Illustration of the camera without the lens

  1. 1 button (Custom button 1)/IRIS (Iris) button
  2. Shutter button
  3. W/T (zoom) lever
  4. Front dial

    You can quickly adjust the settings for each shooting mode.

  5. Lens release button
  6. WLAN antenna (built-in)

    Wi-Fi communication may be blocked if you cover this part with your hand, etc.

  7. Visible light and IR sensor

    Do not cover this part during shooting.

  8. Recording lamp
  9. Microphone
  10. 6 button (Custom button 6)/REC (Recording) button
  11. Mounting index
  12. Image sensor*
  13. Mount
  14. Lens contacts*

* Do not directly touch these parts.
