Specifications

General

Mass

  • Approx. 2.60 kg (5 lb 12 oz) (main body only)
    Approx. 2.99 kg (6 lb 9.5 oz) (including lens hood, battery (BP-U35), LCD hood, media)

Dimensions (width × height × depth) (excluding protrusions)

Approx. 182.5 mm (A) × 201.9 mm (B) × 333.9 mm (C) (7 1/4 inch × 8 inch × 13 1/4 inch)

Power requirements

20.0 V DC (19.0 V to 21.0 V)

Power consumption

  • Normal power consumption: Approx. 26 W (main body, XAVC Long, QFHD 59.94P, CFexpress Type A memory card recording, LCD monitor lit (default), no peripherals connected)
    Maximum power consumption: Approx. 47 W (main body, XAVC Intra, QFHD 59.94P, CFexpress Type A memory card recording (2-card simultaneous recording), LCD monitor lit (maximum), peripherals connected (SDI, HDMI, USB, wireless devices))

Operating temperature

0 °C to 40 °C (32 °F to 104 °F)

Storage temperature

−20 °C to +60 °C (−4 °F to +140 °F)

Continuous operating time

Approx. 160 minutes (using BP-U70, normal power consumption)

Recording format (video)

  • XAVC Long
  • XAVC Intra
  • MPEG HD 422

Recording format (audio)

LPCM 24-bit, 48 kHz, 4-channel

Recording frame rate

  • XAVC Long
    3840×2160P/59.94P, 50P, 29.97P, 25P, 23.98P
    1920×1080P/59.94P, 50P, 29.97P, 25P, 23.98P
    1920×1080i/59.94i, 50i
    1280×720P/59.94P, 50P
  • XAVC Intra
    3840×2160P/59.94P, 50P, 29.97P, 25P, 23.98P
    1920×1080P/59.94P, 50P, 29.97P, 25P, 23.98P
    1920×1080i/59.94i, 50i
    1280×720P/59.94P, 50P
  • MPEG HD 422
    1920×1080P/29.97P, 25P, 23.98P
    1920×1080i/59.94i, 50i
    1280×720P/59.94P, 50P

Recording/playback time

  • XAVC Long
    3840×2160P/59.94P
    Approx. 100 minutes (using CEA-G160T)
    1920×1080P/59.94P
    Approx. 270 minutes (using CEA-G160T)
  • XAVC Intra
    3840×2160P/59.94P
    Approx. 25 minutes (using CEA-G160T)
    1920×1080P/59.94P
    Approx. 75 minutes (using CEA-G160T)
  • MPEG HD 422
    1280×720P/59.94P
    Approx. 280 minutes (using CEA-G160T)

Note

  • The recording/playback time may vary due to usage conditions and memory characteristics. The recording and playback times are for a continuous recording as a single clip. The actual times may be shorter, depending on the number of clips recorded.

Camera section

Imaging device

1/2-inch ExmorR 3CMOS sensor

Effective picture elements

3840 (H) × 2160 (V)

Optical system

F1.6 prism system

Internal ND filters

[Clear]: No ND filter

1: 1/4ND

2: 1/16ND

3: 1/64ND

Linearly variable ND: 1/4ND to 1/128ND

Sensitivity (2000 lx, 89.9% reflectance)

F12 (typical, 1920×1080/59.94P mode)

F13 (typical, 1920×1080/50P mode)

F12 (typical, 3840×2160/59.94P , high sensitivity mode)

F13 (typical, 3840×2160/50P , high sensitivity mode)

Minimum illumination

0.0013 lx (typical, 1920×1080/59.94i)

(F1.9, +42 dB, high sensitivity mode, 64 frames accumulation)

Horizontal resolution

2000 TV lines or more (3840×2160P mode)

1000 TV lines or more (1920×1080P mode)

Shutter speed

64F to 1/8000 sec.

Slow & Quick Motion

  • XAVC Long, XAVC Intra:
    2160P: 1 to 60 frames
    1080P: 1 to 60, 100, 120 frames
    720P: 1 to 60 frames

  • MPEG HD 422:
    1080P: 1 to 60 frames
    720P: 1 to 60 frames

White balance

Preset mode (3200K), memory A mode, memory B mode/ATW mode

Gain

−3 dB to +18 dB (1 dB increments), 42 dB (turbo gain mode), [AGC]

Base look

[S-Cinetone] / [ITU709] / [709tone] / [HLG Live] / [HLG Mild] / [HLG Natural] / [S-Log3]

Lens section

Lens mount

Fixed

Optical zoom ratio

17×

Focal length

5.6 mm to 95.2 mm

(35 mm equivalent: 30.3 mm to 515 mm)

Focus

AF/MF/Full MF selectable

Focus range

AF/MF/Full MF selectable

800 mm to ∞ (macro off)

50 mm to ∞ (macro on, wide)

800 mm to ∞ (macro on, tele)

Iris

Aperture (F number): F1.9 to F16, closed (auto/manual selectable)

Image stabilization

Shift lens method (on/off selectable)

Filter diameter

ø77 mm, 0.75 mm pitch

Macro

On/off selectable

Audio section

Sampling frequency

48 kHz

Quantization

24-bit

Frequency response

XLR input MIC mode: 20 Hz to 20 kHz (±3 dB or less)

XLR input LINE mode: 20 Hz to 20 kHz (±3 dB or less)

Dynamic range

XLR input MIC mode: 80 dB (−50 dB reference level, typical)

XLR input LINE mode: 90 dB (+4 dB reference level, typical)

Distortion

XLR input MIC mode: 0.08% or lower (−50 dB reference level, −40 dBu input level, 1 kHz)

XLR input LINE mode: 0.08% or lower (+4 dB reference level, +14 dBu input level, 1 kHz)

Built-in speaker

Monaural

Internal microphone

Omnidirectional stereo electret condenser microphone

Input/output section

Inputs

INPUT 1/2: XLR type, 3-pin, female

LINE / MIC / MIC+48V switchable

MIC: Reference −30 dBu to −80 dBu

TC IN: BNC type

GENLOCK IN: BNC type

Outputs

SDI OUT: BNC type, 12G-SDI, 6G-SDI, 3G-SDI (Level A/B), HD-SDI

Headphones (stereo mini jack): −15 dBu (reference level output, maximum monitor volume, 16 Ω load)

HDMI: Type A, 19-pin

TC OUT: BNC type

REF OUT: BNC type (GENLOCK IN connector selectable)

Other

DC IN: USB Type-C connector, 19.0 V to 21.0 V DC

Multi interface shoe: Dedicated 21-pin

REMOTE: ø2.5 mm 3-pole sub-mini type

USB-C: USB 3.2 Gen 1

Grip remote control connector: ø3.5 mm 4-pole stereo mini type

Display section

LCD monitor

Screen size: 8.8 cm (3.5 inch) diagonal

Aspect ratio: 16:9

Number of pixels: 1280 (H) × 720 (V)

Media slot section

CFexpress Type A/SD card slot (2)

Wired LAN

RJ45 type

1000BASE-T, 100BASE-TX, 10BASE-T

Wireless LAN

Supported standards

IEEE 802.11a*/b/g/n/ac*

Frequency band

2.4 GHz/5 GHz*

Security

WPA2-PSK (AES) / WPA3-SAE

Connection method

Wi-Fi Protected Setup™ (WPS)/Manual

Access method

Infrastructure mode



* The unit is designed to comply with the communications regulations of your country or region. The 5 GHz band may not be available, depending on the country or region of purchase.

Bluetooth

Communication method

Bluetooth compliant standard Ver. 5.0

Frequency band

2.4 GHz (2.4000 GHz to 2.4835 GHz)

Supplied accessories

  • LCD hood (1)
  • Lens hood (1)
  • V-shoe attachment (1)
  • Before Using This Unit (1)
  • Warranty booklet (1)

Design and specifications are subject to change without notice.
