Bottom Side

Illustration of bottom side of camera

  1. Tripod screw holes

    Compatible with 1/4 inch (1/4-20 UNC) and 3/8 inch (3/8-16 UNC) screws. Attach to a tripod (option, screw length of 5.5 mm or shorter).

  2. Zoom servo switch

    Switches the zoom operating mode.

    • SERVO: Adjusts the zoom using the handle zoom lever or grip zoom lever.
    • MANUAL: Adjusts the zoom manually using the zoom ring.

  3. WB SET button

    When the WHT BAL switch is set to A or B and the WB SET button is pressed, auto white balance is activated and white balance data is saved in internal memory.
