Top Side/Handle

Illustration of top side of camera

  1. Accessory shoe

  2. Record START/STOP button / HOLD switch (handle)

    Press the record START/STOP button, turning the light on, to start recording. Press again, turning the light off, to stop recording.

    When the HOLD switch is in the HOLD position, the record START/STOP button cannot be pressed.

  3. Handle zoom lever

    Adjusts the zoom between wide angle and telephoto. Move it slightly to zoom slowly, and move it further to zoom faster.

  4. ASSIGN (assignable) 9 button
  5. ASSIGN (assignable) 10 button

  6. Multi selector

    Used for auto focus operation and menu operation. Moves the cursor in 8 directions and selects values when pressed.

  7. Volume button

    Adjusts the volume of headphones/built-in speaker.

  8. DISPLAY button

    Shows/hides the status and settings of the unit.

    Press for 10 seconds or longer to switch the HDMI output to 1920×1080 or 1280×720P, and enables the on-screen display overlay.

  9. Accessory attachment screw hole

    1/4 inch screw hole compatible with 1/4-20 UNC screws (length of 6 mm or shorter).

    Note

    • Use of screws longer than 6 mm may damage exterior parts.

  10. Accessory shoe mount/Accessory attachment screw hole

    1/4 inch screw hole compatible with 1/4-20 UNC screws (length of 6 mm or shorter).

    Note

    • Use of screws longer than 6 mm may damage exterior parts.

  11. Zoom lever (grip)

    Adjusts the zoom between wide angle and telephoto. Move it slightly to zoom slowly, and move it further to zoom faster.

  12. DIRECT MENU / ASSIGN (assignable) 5 button
  13. FOCUS MAG / ASSIGN (assignable) 4 button

  14. THUMBNAIL button

    Press the button during shooting mode or playback mode to display the thumbnail screen. Press again to return to shooting mode.

  15. LCD ADJUST button

    Displays the level bar for LCD monitor brightness adjustment. Adjust using the multi selector or multi-function dial.

  16. F REV button

    Plays video in the reverse direction at high speed. Press the button again to increase the speed (3 steps).

  17. PLAY/PAUSE button

    Pauses playback. Press again to resume normal playback.

  18. F FWD button

    Plays video in the forward direction at high speed. Press the button again to increase the speed (3 steps).

  19. PREV button

    Jumps to the first image of the clip. If already positioned at the first image, it jumps to the start of the previous clip. When the F REV button is pressed while the PREV button is pressed, it jumps to the start of the first clip on the memory card.

  20. STOP/CAM button

    Press during playback to stop playback.

  21. NEXT button

    Jumps to start of next clip.

    If viewing the last clip, it jumps to the end of the clip. When the F FWD button is pressed while the NEXT button is pressed, it jumps to the end of the last clip on the memory card.

  22. Lens hood release button
