Specifications
Unit
[Type]
Camera type
Interchangeable lens digital camera
Lens
Sony E-mount lens
[Imager]
Imaging element
35 mm full-frame (35.9 mm × 24.0 mm), CMOS image sensor
Number of pixels (effective)
Approx. 16 600 000 pixels
Number of pixels (total)
Approx. 18 200 000 pixels
Latitude
15+ stops (S-Log3)
Color temperature range
2000 K to 15000 K
[Image stabilization]
Type
Image sensor shift type (internal)
[Anti-Dust function]
System
Anti-dust function using antistatic coating and ultrasonic vibration
[Auto focus]
Detection method
Phase detection/contrast detection
[Monitor]
LCD monitor
8.8 cm (3.5 inch) TFT, touch panel
Number of dots
2 764 800 dots
[Recording media]
CFexpress Type A memory cards, SD cards
[Slots]
Slot A / Slot B
CFexpress Type A memory card, SD (UHS-I, UHS-II compliant) card slots
[Input/output connectors]
USB Type-C connector (USB PORT 1)
USB communication SuperSpeed USB 10 Gbps (USB 3.2)
USB Power Delivery compatible
USB Type-C connector (USB PORT 2)
USB communication Hi-Speed USB 480 Mbps (USB 2.0)
USB Power Delivery compatible
HDMI connector
HDMI type A connector
LAN connector
2.5GBASE-T, 1000BASE-T, 100BASE-TX
Microphone connector
Ø3.5 mm stereo mini jack
Headphone connector
Ø3.5 mm stereo mini jack
[Power supply, Other]
Rated input
7.82 V
Power consumption
When using FE 28-70mm F3.5-5.6 OSS II lens
Approx. 7.4 W
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
−20 °C to +55 °C (−4 °F to +131 °F)
Dimensions (width × height × depth) (Approx.)
132.2 mm × 79.0 mm × 87.0 mm
5 1/4 in. × 3 1/8 in. × 3 1/2 in.
Mass (Approx.)
734 g (1 lb 9.9 oz) (including battery pack, SD card)
Microphone
Stereo
Speaker
Monaural
[Energy saving]
Power consumption (off mode)
Not supported
Power consumption (standby mode/low-voltage mode)
0.5 W
Power consumption (network standby mode)
2.0 W (Bluetooth) / 2.0 W (LAN) / 2.0 W (all connectors connected and network connected)
Energy saving mode enable
Within 20 minutes (default)
Network standby mode enable
Within 20 minutes (default)
[Wireless LAN]
WW789166 (see nameplate on bottom of camera)
Supported standards: IEEE 802.11 a/b/g/n/ac/ax
Frequency band: 2.4 GHz / 5 GHz / 6 GHz
WW679476 (see nameplate on bottom of camera)
Supported standards: IEEE 802.11 a/b/g/n/ac/ax
Frequency band: 2.4 GHz / 5 GHz
WW199569 (see nameplate on bottom of camera)
Supported standards: IEEE 802.11 b/g/n/ax
Frequency band: 2.4 GHz
Security
WPA2-PSK (AES) / WPA3-SAE
Connection method
Wi-Fi Protected Setup™ (WPS)/Manual
Access method
Infrastructure mode
[Bluetooth communication]
Bluetooth compliant standard Ver. 5.3
Frequency band
2.4 GHz
XLR-H2 XLR Handle Unit (ILME-FX5 only)
INPUT1/INPUT2 connectors (XLR/TRS*1 type, 3-pin, female, +48 V phantom power supply compatible)
MIC
Reference input level: −50 dBu (ATT = 10)
Reference recording level: −20 dBFS
LINE
Reference input level: +4 dBu
Reference recording level: −20 dBFS
INPUT3 connector (stereo mini jack, plug-in power compatible)
Reference input level: −66 dBu (ATT = 10)
Reference recording level: −20 dBFS
(0 dBu = 0.775 Vrms)
Mass (Approx.)
312 g (11.1 oz)
*13-pole jack (Tip: Hot, Ring: Cold, Sleeve: GND)
BC-SAD1 battery charger
Rated input
15 V , 3 A
Rated output
8.9 V , 2.7 A × 1
8.9 V , 1.9 A × 2
NP-SA100 rechargeable battery pack
Rating
7.82 V
Recommended USB PD compatible AC adaptor
Input
100 V to 240 V
, 50/60 Hz
Output
9 V / 3 A or higher
Design and specifications are subject to change without notice.
Trademarks and licenses
- “ɑ” and “
” are trademarks of Sony Group Corporation. - XAVC S and
are trademarks of Sony Group Corporation. - XAVC HS and
are trademarks of Sony Group Corporation. - Mac is a trademark of Apple Inc., registered in the U.S. and other countries and regions.
- AOSS is a trademark of Buffalo, Inc.
- USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
- The terms HDMI™, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
- Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
- The SDXC logo is a trademark of SD-3C, LLC.
- CFexpress™ is a trademark owned solely and exclusively by the CompactFlash Association.
- Wi-Fi, Wi-Fi logo, and Wi-Fi Protected Setup are trademarks or registered trademarks of Wi-Fi Alliance.
- The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sony Group Corporation and its subsidiaries is under license.
- QR Code is a trademark of Denso Wave Inc.
- All other system names and product names are registered trademarks or trademarks of their respective owners. Trademarked items are not indicated by ® or ™ symbols in this Help Guide.
Maximum external dimensions
Maximum external dimensions, including protrusions (approximate values)
Units: mm (inch)
