List of icons on the screen for shooting still images

The displayed contents and their positions in the illustrations are just guidelines, and may differ from the actual displays. Also, the displayed contents may vary depending on your camera’s system software (firmware) version.

Descriptions are given below the indications of the icons.

Monitor mode

Illustration of the screen in the monitor mode

Viewfinder mode

Illustration of the screen in the viewfinder mode

  1. Shooting mode/Scene recognition
    Shooting mode
    Shooting mode (Recall Camera Setting)
    Scene Recognition icons
  2. Camera settings
    Memory card for recording / Not memory card for recording
    NO CARD
    No memory card inserted
    Near the rewriting upper limit of the memory card / Rewriting upper limit of the memory card reached
    100
    Remaining number of recordable images
    Writing data / Number of images left to write
    60M / 54M / 51M / 40M / 26M / 23M / 22M / 17M / 15M / 13M / 10M
    Image size of still images
    RAW recording (compressed/lossless compression (L/M/S)/uncompressed)
    J-X.FINE J-FINE J-STD J-LIGHT H-X.FINE H-FINE H-STD H-LIGHT
    JPEG Quality / HEIF Quality
    4:2:2
    Color sampling for HEIF
    Flash charge in progress
    Setting Effect OFF
    Exposure Effect (Exposure Setting Only)
    AF Illuminator
    Flickering detected
    SteadyShot off/on, Camera shake warning
    SteadyShot focal length / Camera shake warning
    Optical zoom only /Clear Image Zoom/Digital Zoom
    Remote Shooting (connected) / Remote Shooting (connection error)
    Bright Monitoring
    Silent mode
    Remote control
    Connected to the cloud / Communicating with the cloud / Cloud connection error
    Connected with FTP / FTP communication in progress / FTP connection error
    Transferring to smartphone / Transfer error
    Connected to Wi-Fi (via a Wi-Fi access point)
    Disconnected from Wi-Fi (via a Wi-Fi access point)
    Connected to Wi-Fi/Disconnected from Wi-Fi (Wi-Fi Direct)
    Connected to LAN/Disconnected from LAN (When using a USB-LAN conversion adaptor)
    Writing copyright information [On]
    Writing IPTC information [On]
    Touch function in shooting mode (Touch focus/Touch tracking/Touch shutter/off)
    Focus Cancel
    Tracking Cancel
    Bluetooth connection available / Bluetooth connection unavailable
    Obtaining location information / Location information cannot be obtained
    Airplane Mode
    Overheating warning
    Database file full / Database file error
    Tripod recognition
  3. Battery
    Remaining battery
    Remaining battery warning
    USB power supply
  4. Shooting settings
    Drive Mode
    Flash Mode / Wireless Flash / Red Eye Reduction
    ±0.0
    Flash Comp.
    Focus Mode
    Focus Area
    Metering Mode
    7500K A5 G5
    White Balance (Auto, Preset, Underwater Auto, Custom, Color temperature, Color filter)
    D-Range Optimizer
    Creative Look
    Subject Recog in AF/ Recognition Target
    –
    Picture Profile
    Shutter Type
    Rec. Media Settings
    Finder Frame Rate
    Aspect ratio
  5. Focus indicator/exposure settings
    Focus indicator
    1/250
    Shutter speed
    F3.5
    Aperture value
    Exposure compensation/Metered Manual
    ISO400 ISO AUTO
    ISO sensitivity
    AE lock/FEL lock/AWB lock
    Shooting
  6. Guides/other
    Tracking Cancel
    Guide display for tracking
    Focus Cancel
    Guide display for canceling focusing
    Guide display for dials
    Anti-flicker Tv Scan


    Bracket indicator

    Spot metering area
    Histogram
    Digital level gauge
    2/4
    Pixel Shift Multi Shoot.
