List of icons on the playback screen
The displayed contents and their positions in the illustrations are just guidelines, and may differ from the actual displays. Also, the displayed contents may vary depending on your camera’s system software (firmware) version.
Descriptions are given below the indications of the icons.
Single-image playback
Histogram display
- Basic information
-
- Playback media
-
- IPTC Information
-
- Rating
-
- Protect
- 3/7
- File number/Number of images in the view mode
-
- Remaining battery
-
- Display as Group
-
- Cropped image
-
- Proxy movie included
-
000000 2/4
- Pixel Shift Multi Shoot.
-
- Shot Mark included
-
- FTP transfer status
-
- Smartphone transfer status (when using [
Select on Cam & Send])
-
- Camera settings
-
- Connected to the cloud /Communicating with the cloud / Cloud connection error
-
- Connected with FTP / FTP communication in progress / FTP connection error
-
- Transferring to smartphone / Transfer error
-
- Connected to Wi-Fi (via a Wi-Fi access point)
-
- Disconnected from Wi-Fi (via a Wi-Fi access point)
-
- Connected to Wi-Fi/Disconnected from Wi-Fi (Wi-Fi Direct)
-
- Connected to LAN/Disconnected from LAN (When using a USB-LAN conversion adaptor)
-
- Bluetooth connection available / Bluetooth connection unavailable
-
- Airplane Mode
-
- Overheating warning
-
- Database file full / Database file error
-
-
Shooting settings
-
- Aspect ratio
- 60M / 54M / 51M / 40M / 26M / 23M / 22M / 17M / 15M / 13M / 10M
- Image size of still images
-
- RAW recording
- J-X.FINE J-FINE J-STD J-LIGHT H-X.FINE H-FINE H-STD H-LIGHT
- JPEG Quality/HEIF Quality
- 4:2:2
- Color sampling for HEIF
- XAVC HS 8K XAVC HS 4K XAVC S 4K XAVC S HD XAVC S-I 4K XAVC S-I HD
- File format of movies
- 120p 100p 60p 50p 30p 25p 24p
- Frame rate of movies
-
- Record setting of movies
- 1/250
- Shutter speed
- F3.5
- Aperture value
- ISO400
- ISO sensitivity
- P A S M
- Exposure mode
-
- Exposure compensation
-
- Metering Mode
- 35mm
- Lens focal length
-
-
Creative Look
-
7500K A5 G5
- White Balance (Auto, Preset, Underwater Auto, Color temperature, Color filter)
-
-
D-Range Optimizer
- HLG
- HDR recording (Hybrid Log-Gamma)
-
- Copyright information exists for image
-
- Image information
-
- Latitude/longitude information
- 2022-1-1 10:37:00PM
- Date of recording
-
100-0003 - Folder number - file number
- C0003
- Movie file number
-
- Histogram (Luminance/R/G/B)
-
